ABB 1SBL41 Contactor, 130V, 40 V Coil, 3-Pole, 125 A, 37 kW 130V, 48 V, 3 NO, 690V

RS Stock No.:: 253-2037
Mfr. Part No.:: 1SBL417001R6900
Manufacturer:: ABB

ABB 1SBL41 Contactor, 130V, 40 V Coil, 3-Pole, 125 A, 37 kW 130V, 48 V, 3 NO, 690V

View all Contactors

Subtotal (1 unit)*

SGD877.13

(exc. GST)

SGD956.07

(inc. GST)

Stock information currently inaccessible - Please check back later

Units	Per unit
1 +	SGD877.13

*price indicative

RS Stock No.:: 253-2037
Mfr. Part No.:: 1SBL417001R6900
Manufacturer:: ABB

Specifications

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	ABB
	Coil Voltage	130, 40V
	Product Type	Contactor
	Number of Poles	3
	Contact Voltage	690V
	Contact Current	125A
	Series	1SBL41
	Power Rating	37kW
	Function	Motor Control
	Normal State Configuration	3 NO
	Auxiliary Contact Configuration	0 NO/0 NC
	Number of Auxiliary Contacts	0
	Terminal Type	Screw
	Control Circuit Voltage Uc	130, 48V
	Contactor Application	Control Unit
	Operational Current Ie	72A
	Minimum Operating Temperature	-25°C
	Maximum Operating Temperature	55°C
	Width	70mm
	Length	108mm
	Standards/Approvals	IEC/EN 60947-4-1, CSA C22-2 N°14, IEC/EN 60947-1, UL 508
	Depth	108mm
	Pole and Throw Configuration	3P

	Select all
	Brand ABB
	Coil Voltage 130, 40V
	Product Type Contactor
	Number of Poles 3
	Contact Voltage 690V
	Contact Current 125A
	Series 1SBL41
	Power Rating 37kW
	Function Motor Control
	Normal State Configuration 3 NO
	Auxiliary Contact Configuration 0 NO/0 NC
	Number of Auxiliary Contacts 0
	Terminal Type Screw
	Control Circuit Voltage Uc 130, 48V
	Contactor Application Control Unit
	Operational Current Ie 72A
	Minimum Operating Temperature -25°C
	Maximum Operating Temperature 55°C
	Width 70mm
	Length 108mm
	Standards/Approvals IEC/EN 60947-4-1, CSA C22-2 N°14, IEC/EN 60947-1, UL 508
	Depth 108mm
	Pole and Throw Configuration 3P

Datasheet - 1SBL417001R6900

ABB 1SBL41 Series Contactor, 125A Contact Current, 690V Contact Voltage - 1SBL417001R6900

This contactor is a three-pole switching device designed for motor control and power-circuit switching up to 690V AC. It is intended for industrial automation and electrical installations where controlled switching of three-phase motors and DC control circuits is required. The unit operates across a range of control voltages and is built to function in typical industrial ambient temperatures.

Features and Benefits:

• 125A rated contacts providing high-current switching capability
• 690V contact voltage enabling heavy-duty power-circuit use
• 72A operational current suited to continuous motor loads
• 37kW power rating supporting substantial motor-drive capacity
• 48–130V Coil compatibility allowing flexible control-supply options
• Screw terminals ensuring secure conductor connections

Applications

• Suitable for controlling three-phase motor starting and stopping
• Can be used for power circuits in industrial switchgear up to 690V AC
• Ideal for systems where 220V DC control inputs are present
• Used with automation panels requiring 48–130V control coils
• Suitable for retrofit or replacement in industrial motor-control assemblies

What control voltage range can be used to operate the coil?

The control Coil accepts voltages from 48V up to 130V, covering typical DC and low-voltage AC control supplies.

What environmental temperature limits should be observed during operation?

The device is rated for operation down to −25°C and up to 55°C ambient temperature.

How many main switching poles and auxiliary contacts are provided?

The unit has three main switching poles configured as normally open and contains no auxiliary contacts.

What standards does the unit conform to for industrial use?

It meets recognised international standards for contactors and switching devices, including relevant IEC/EN and UL specifications.
