Belden70045LV Series 2 Core Speaker Cable, 1.5 mm² CSA, 6.8mm od, 100m, Black

RS Stock No.:: 187-6121
Mfr. Part No.:: 70045LV.00100
Manufacturer:: Belden

Belden70045LV Series 2 Core Speaker Cable, 1.5 mm² CSA, 6.8mm od, 100m, Black

Subtotal (1 reel of 100 metres)*

SGD561.74

(exc. GST)

SGD612.30

(inc. GST)

FREE delivery for orders over $150, or create a business account to enjoy free delivery from just $28

In Stock

4 unit(s) ready to ship from another location

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Reel(s)	Per Reel	Per Metre*
1 +	SGD561.74	SGD5.617

*price indicative

RS Stock No.:: 187-6121
Mfr. Part No.:: 70045LV.00100
Manufacturer:: Belden

Specifications

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Belden
	Audio Cable Type	Speaker Cable
	Number of Cores	2
	Cross Sectional Area	1.5 mm²
	Insulation Material	LSZH
	Outer Diameter	6.8mm
	Length	100m
	Minimum Operating Temperature	-5°C
	CPR Certification	B2ca
	Maximum Operating Temperature	+70°C
	Fire Behaviour	Flame Retardant
	Sheath Colour	Black
	Conductor Resistance	13 Ω/km
	Voltage Rating	300 V
	Standards Met	Euroclass B2ca-s1 d1 a1
	Number of Strands	30
	Series	70045LV
	Conductor Strand Type	Stranded
	Sheath Material	Low Smoke Zero Halogen (LSZH)
	Core Strands	30/0.25 mm
	Conductor Material	Bare Copper
	Cable Shape	Multicore

	Select all
	Brand Belden
	Audio Cable Type Speaker Cable
	Number of Cores 2
	Cross Sectional Area 1.5 mm²
	Insulation Material LSZH
	Outer Diameter 6.8mm
	Length 100m
	Minimum Operating Temperature -5°C
	CPR Certification B2ca
	Maximum Operating Temperature +70°C
	Fire Behaviour Flame Retardant
	Sheath Colour Black
	Conductor Resistance 13 Ω/km
	Voltage Rating 300 V
	Standards Met Euroclass B2ca-s1 d1 a1
	Number of Strands 30
	Series 70045LV
	Conductor Strand Type Stranded
	Sheath Material Low Smoke Zero Halogen (LSZH)
	Core Strands 30/0.25 mm
	Conductor Material Bare Copper
	Cable Shape Multicore

COO (Country of Origin):: NL

Belden Audio Cable, 2 Cores, 6.8mm OD - PB00179 Series - 70045LV.00100

Go for this audio cable from Belden to get your speakers into the groove of quality performance. With an outer diameter of only 6.8mm, it gets in and around complex setups with ease. As they're made using an upright shaft manufacturing process, the highly-conductive copper conductors deliver pure sounds ringing with clarity. This product's low-flame spread and heat-release properties make it a fire-safe option in any environment.

Features & Benefits

• Grey jacket colour for easy identification
• Flexible, so easily navigates bends around equipment
• 100-metre length for long runs or lots of smaller jobs

Applications

• Media entertainment systems
• PA equipment
• Concert setups

Why does this audio cable have an LSZH sheath?

LSZH stands for low-smoke, zero-halogen and has to do with a product's fire safety. This means the cable jacket releases minimal smoke when it catches fire and contains no toxins that can harm you.
