Backplane Connectors

Backplane connectors are electrical parts used to connect several printed circuit boards (PCBs) together within a computer system. Each pin on every backplane connector is linked to the same relative pin of all the other connectors to form a computer bus transceiver. Backplane connectors provide stable electrical connections between the components and the printed circuit boards.

What are backplane connectors used for?

Backplane connectors are used in PCBs for computerised devices. Wire-wrapped connectors are typically used in minicomputers and high-reliability applications in the manufacturing industry. Backplane connectors function as safety parts in heavier components like video cards and peripheral devices to ensure these do not damage the PCB or become disconnected.

Types of backplane connectors

There are three types of backplane connector:

  • Butterfly backplane connectors are used in boards with switchless designs, to lower data latency and overall system cost.
  • Active backplane connectors are standard in boards that contain a bus control and motherboard circuitry but no complex processor components.
  • Passive backplane connectors are universal in boards with buses and drivers that need to transmit data and interface with the operating system.

...
Read more Read less

Filters

Viewing 1 - 20 of 496 products
Results per page
Description Price Backplane Connector Type Gender Number of Contacts Number of Columns Number of Rows Body Orientation Housing Material Pitch Contact Material Mounting Type Contact Plating Current Rating Voltage Rating Termination Method
RS Stock No. 341-8987
Mfr. Part No.127050-0216
BrandITT Cannon
SGD99.66
Each
units
- Female 96 - - Straight Aluminium Alloy - Beryllium Copper - Gold 5A 1.2 kV ac -
RS Stock No. 341-8959
Mfr. Part No.127050-0212
BrandITT Cannon
SGD169.93
Each
units
- Male 96 - - Straight Aluminium Alloy - Beryllium Copper - Gold 5A 1.2 kV ac -
RS Stock No. 739-0990
Mfr. Part No.5352268-1
SGD24.78
Each
units
Hard Metric Type B Female 110 22 5 Straight Glass Fibre Reinforced PBT 2mm Phosphor Bronze Through Hole - - - Solder
RS Stock No. 259-9625
Mfr. Part No.516-056-000-401
BrandEDAC
SGD17.43
Each
units
- Female 56 - - Straight Plastic 3.81mm Phosphor Bronze - Gold 8.5A - -
RS Stock No. 657-1536
Mfr. Part No.5106773-1
SGD22.70
Each
units
Hard Metric Type A Female 110 - 5 - PET 2mm Phosphor Bronze Through Hole Gold over Nickel - - Press-In
RS Stock No. 447-083
Mfr. Part No.DRP116
BrandMcmurdo
SGD83.80
Each
units
- Male 16 - 2 Straight DAP 4.7mm Copper Alloy - Gold 5A 800 V ac/dc Solder
RS Stock No. 129-6094
Mfr. Part No.DL3-60P
BrandITT Cannon
SGD95.30
Each
units
- Male 60 - - Straight Thermoplastic 2.54mm Copper Alloy - Gold over Nickel 5A - -
RS Stock No. 182-3151
Mfr. Part No.10029364-001LF
SGD5.03
Each
units
- - - - - - - - - - - - - -
RS Stock No. 182-2893
Mfr. Part No.10029364-001LF
SGD4.376
Each (In a Tray of 330)
units
- Female 22 - 2 Right Angle Thermoplastic - Copper Alloy Surface Mount Gold 1.5A 500 V ac Solder
RS Stock No. 917-5229
Mfr. Part No.354865
BrandERNI
SGD6.14
Each
units
Hard Metric Type C Female 55 11 5 Right Angle Liquid Crystal Polymer, PBT 2mm Phosphor Bronze - Gold 1.5A - Press Fit
RS Stock No. 170-6915
Mfr. Part No.354865
BrandERNI
SGD4.88
Each (In a Tray of 64)
units
Hard Metric Type C Female 55 11 5 Right Angle Liquid Crystal Polymer, PBT 2mm Phosphor Bronze - Gold 1.5A - Press Fit
RS Stock No. 896-7529
Mfr. Part No.87779-1001
BrandMolex
SGD4.68
Each (In a Pack of 2)
units
- Female 22 - 1 Vertical Liquid Crystal Polymer 1.27mm Copper Alloy - Gold over Nickel 1.5A 30 V Solder
RS Stock No. 167-6400
Mfr. Part No.87779-1001
BrandMolex
SGD4.03
Each (In a Tray of 30)
units
- Female 22 - 1 Vertical Liquid Crystal Polymer 1.27mm Copper Alloy - Gold over Nickel 1.5A 30 V Solder
RS Stock No. 341-8965
Mfr. Part No.127050-0204
BrandITT Cannon
SGD201.59
Each
units
- Male 156 - - Straight Aluminium Alloy - Beryllium Copper - Gold 5A 1.2 kV ac -
RS Stock No. 828-2086
Mfr. Part No.MP2-H024-41P1-S-LR
Brand3M
SGD3.29
Each (In a Pack of 1008)
units
- Male 24 - 4 Straight Liquid Crystal Polymer 2mm Phosphor Bronze - Gold over Palladium Nickel over Nickel 1.5A - Press-In
RS Stock No. 164-1649
Mfr. Part No.5100143-1
SGD9.22
Each (In a Tube of 10)
units
Hard Metric Type A Male 110 22 5 Straight PBT 2mm Phosphor Bronze Through Hole Gold over Nickel 1.5A 500 V ac Press-In
RS Stock No. 340-1018
Mfr. Part No.5100143-1
SGD9.60
Each
units
Hard Metric Type A Male 110 22 5 Straight PBT 2mm Phosphor Bronze Through Hole Gold over Nickel 1.5A 500 V ac Press-In
RS Stock No. 259-9580
Mfr. Part No.516-038-000-302
BrandEDAC
SGD12.11
Each
units
- Male 38 - - Straight - - Phosphor Bronze - Gold 8.5A - -
RS Stock No. 910-6778
Mfr. Part No.516-290-591
BrandEDAC
SGD923.40
1 Reel of 1800
Reel(s)
- - - - - Straight - - Phosphor Bronze Alloy - Gold over Nickel 8.5A - -
RS Stock No. 170-6918
Mfr. Part No.114028
BrandERNI
SGD61.099
Each (In a Tray of 45)
units
Hard Metric Type C Female 55 11 5 Vertical Liquid Crystal Polymer 2mm Phosphor Bronze - Gold 1.5A - Press Fit
