MEAN WELL Switching Power Supply, HRPG-150-12 12V dc, 13 A, 156 W, Input 85V ac to 370 V dc, 264V ac
- RS Stock No.:
- 721-1658
- Mfr. Part No.:
- HRPG-150-12
- Manufacturer:
- MEAN WELL
Bulk discount available
Subtotal (1 unit)*
SGD93.15
(exc. GST)
SGD101.53
(inc. GST)
FREE delivery for orders over $150, or create a business account to enjoy free delivery from just $28
In Stock
- Plus 49 unit(s) shipping from 09 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | SGD93.15 |
| 10 - 49 | SGD91.29 |
| 50 + | SGD89.46 |
*price indicative
- RS Stock No.:
- 721-1658
- Mfr. Part No.:
- HRPG-150-12
- Manufacturer:
- MEAN WELL
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | MEAN WELL | |
| Product Type | Switching Power Supply | |
| Maximum Output Voltage | 12V dc | |
| Number of Outputs | 1 | |
| Mount Type | Chassis | |
| Power | 156W | |
| SMPS Output Current | 13 A | |
| Minimum Operating Temperature | -30°C | |
| Maximum Operating Temperature | 70°C | |
| Length | 159mm | |
| Standards/Approvals | TUV BS ENEN 6681, UL 6681, ASNZS 668.1, EAC TP TC 004 | |
| Width | 38 mm | |
| Depth | 38mm | |
| Weight | 630g | |
| Maximum Input Voltage | 370, 264V dc | |
| Efficiency | 87% | |
| Series | HRPG-150 | |
| Output Current | 13A | |
| Minimum Input Voltage | 85V ac | |
| Hazardous Area Certification | No | |
| Select all | ||
|---|---|---|
Brand MEAN WELL | ||
Product Type Switching Power Supply | ||
Maximum Output Voltage 12V dc | ||
Number of Outputs 1 | ||
Mount Type Chassis | ||
Power 156W | ||
SMPS Output Current 13 A | ||
Minimum Operating Temperature -30°C | ||
Maximum Operating Temperature 70°C | ||
Length 159mm | ||
Standards/Approvals TUV BS ENEN 6681, UL 6681, ASNZS 668.1, EAC TP TC 004 | ||
Width 38 mm | ||
Depth 38mm | ||
Weight 630g | ||
Maximum Input Voltage 370, 264V dc | ||
Efficiency 87% | ||
Series HRPG-150 | ||
Output Current 13A | ||
Minimum Input Voltage 85V ac | ||
Hazardous Area Certification No | ||
- COO (Country of Origin):
- CN
HRPG-150 Series Single Output Power Supply with PFC Function
High efficiency, long life and high reliability
No load power consumption <0.5W
Built-in active PFC function
Built-in constant current limiting circuit
Built-in remote sense function
Built-in remote ON-OFF control
Short circuit, over load, over voltage and over temperature protection
Withstands 300Vac surge input for 5 seconds
1U low profile 38mm
Power factor correction to EN61000-3-2,-3
EMC compliance to EN55022 class B
Note
Power derates above 40°C.
MTBF to MIL-HDBK-217F.
MTBF to MIL-HDBK-217F.
Approvals
UL/cUL recognised, TUV, CB
Standards
UL60950-1, TUV EN60950-1
