The RAC04-GA series are low cost AC/DC power supplies, ideal for PCB mounted, compact, board level industrial applications. They feature universal AC input voltage range, regulated and short-circuit-proof isolated DC outputs, low standby power consumption and -40°C to +85°C operating temperature range. The RAC04-GA have a built-in Class A / FCC Part 15 EMC filter, are certified to IEC/EN/UL60950-1 and EN60335 and are pending to IEC/EN/UL62368 and EN61558 safety standards and come with a three year warranty.

Universal Input 85-305VAC
4W PCB Mount Package
<75mW No Load Power Consumption
Ultra Low Profile, Compact Size
-40°C to +85°C Operating Temperature
Continuous SCP, OCP, OVP
EN60335, EN60950, UL60950 & CE Pending

Tube(s)	Per Tube	Per unit**
1 - 1	SGD309.48	SGD15.474
2 - 3	SGD302.67	SGD15.134
4 +	SGD296.17	SGD14.808

Select all	Attribute	Value
	Brand	Recom
	Output Voltage	5V dc
	Output Current	800mA
	Power Rating	4W
	Number of Outputs	1
	Input Voltage	305 V ac, 430 V dc
	Mounting Type	PCB Mount
	Package Type	Encapsulated
	Length	37mm
	Width	24mm
	Depth	15mm
	Series	RAC04-GA
	Maximum Temperature	+70°C
	Weight	20g
	Minimum Temperature	-40°C

	Select all
	Brand Recom
	Output Voltage 5V dc
	Output Current 800mA
	Power Rating 4W
	Number of Outputs 1
	Input Voltage 305 V ac, 430 V dc
	Mounting Type PCB Mount
	Package Type Encapsulated
	Length 37mm
	Width 24mm
	Depth 15mm
	Series RAC04-GA
	Maximum Temperature +70°C
	Weight 20g
	Minimum Temperature -40°C

Recom Switching Power Supply, RAC04-05SGA, 5V dc, 800mA, 4W, 1 Output, 305 V ac, 430 V dc Input Voltage
