Sensata / Crydom DRACN Series Solid State Interface Relay, 30 V dc Control, 2 A Load, DIN Rail Mount
- RS Stock No.:
- 720-3997
- Mfr. Part No.:
- DRA-CN240A24
- Manufacturer:
- Sensata / Crydom
55 In stock for delivery within 4 working days
Added
Price Each
SGD74.01
(exc. GST)
SGD80.67
(inc. GST)
| Units | Per unit |
| 1 - 4 | SGD74.01 |
| 5 + | SGD72.16 |
- RS Stock No.:
- 720-3997
- Mfr. Part No.:
- DRA-CN240A24
- Manufacturer:
- Sensata / Crydom
Legislation and Compliance
- COO (Country of Origin):
- MX
Product Details
Sensata | Crydom Solid-State Interface Relay, 4mA Off-State Leakage Current, DIN Rail Mounting - DRACN Series - DRA-CN240A24
Looking to flip the switch on the power to your system? Choose this solid-state interface relay from Sensata | Crydom to turn the flow of electricity on and off. A wide operating temperature range between -25°C and +60°C means it holds its own in harsh environments. Mounting is a walk in the park, as you can simply install it on a standard 35mm DIN rail. As it weighs only 31g, it's light as a feather to minimise strain on your equipment. You'll commonly find this unit used in HVAC systems and lighting controls.
Features & Benefits
• Maximum turn-on and turn-off time of half a cycle to minimise downtime
• IP67 rating indicates it's dust-tight and protected against submersion in 1m of water for up to 30 minutes
• Compact dimensions of 92.6 (L) x 6.1 (W) x 80mm (D) to maximise packing space on your rail
• Wide operating voltage range of 24 to 250V AC for versatility
• IP67 rating indicates it's dust-tight and protected against submersion in 1m of water for up to 30 minutes
• Compact dimensions of 92.6 (L) x 6.1 (W) x 80mm (D) to maximise packing space on your rail
• Wide operating voltage range of 24 to 250V AC for versatility
Does this relay have a status indicator?
Yes, it has a yellow LED input status indicator for effortless troubleshooting.
Zero Voltage Relays
Note
Temperature can affect current rating; please consult the data sheet for potential derating.
Specifications
Attribute | Value |
|---|---|
| Maximum Control Voltage | 30 V dc |
| Maximum Load Current | 2 A |
| Mounting Type | DIN Rail |
| Maximum Load Voltage | 250 V ac |
| Minimum Control Voltage | 15 V dc |
| Control Voltage Range | 15 → 30 V dc |
| Switching Type | Zero Cross |
| Load Voltage Range | 24 → 250V ac |
| Minimum Load Voltage | 24 V ac |
| Input Current | 7mA |
| Height | 80mm |
| Length | 92.6mm |
| Minimum Load Current | 70 mA |
| Depth | 6.1mm |
| Series | DRACN |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +60°C |
| Capacitance | 15pF |
| Dimensions | 92.6 x 6.1 x 80mm |
| Off State Leakage Current | 4 mA |
| Maximum Turn On Time | 1/2 cycle |
| Operating Temperature Range | -25 → +60°C |
| Manufacturer Part No. | DRA-CN240A24 |
