3M 3659 Series Flat Cable, Round, 1.27 mm Pitch, 16, 30 m Length
- RS Stock No.:
- 342-8625
- Distrelec Article No.:
- 155-63-742
- Mfr. Part No.:
- 3659/16SF
- Manufacturer:
- 3M
Subtotal (30 metres, on reels of 30)*
SGD495.43
(exc. GST)
SGD540.02
(inc. GST)
FREE delivery for orders over $75.00, or create a business account to enjoy free delivery from just $28
Temporarily out of stock
- 2 unit(s) shipping from 13 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | SGD495.43 | SGD16.514 |
*price indicative
Alternative
This product is not currently available. Here is our alternative recommendation.
1 Reel of 30 Metre(s)
SGD262.08
(exc. GST)
SGD285.67
(inc. GST)
- RS Stock No.:
- 342-8625
- Distrelec Article No.:
- 155-63-742
- Mfr. Part No.:
- 3659/16SF
- Manufacturer:
- 3M
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | 3M | |
| Product Type | Flat Cable | |
| Cable Type | Round | |
| Pitch | 1.27mm | |
| Voltage | 300V | |
| Screened/Unscreened | Screened | |
| Number of Conductors | 16 | |
| American Wire Gauge | 28AWG | |
| Jacket Material | Polyvinyl Chloride | |
| Series | 3659 | |
| Conductor Type | Round | |
| Cable Length | 30m | |
| Standards/Approvals | UL, FT1, (UL) CL2, AWM Style 20267, National Electrical Code Article 725 | |
| Hi-Flex | No | |
| Jacket Colour | Black | |
| Number of Strands | 7 | |
| Fire Behaviour | VW-1 | |
| Minimum Operating Temperature | -20°C | |
| Core Strands | 7 x 36AWG | |
| Conductor Material | Tin Plated Copper | |
| Maximum Operating Temperature | 80°C | |
| Size of Strands | 36AWG | |
| Select all | ||
|---|---|---|
Brand 3M | ||
Product Type Flat Cable | ||
Cable Type Round | ||
Pitch 1.27mm | ||
Voltage 300V | ||
Screened/Unscreened Screened | ||
Number of Conductors 16 | ||
American Wire Gauge 28AWG | ||
Jacket Material Polyvinyl Chloride | ||
Series 3659 | ||
Conductor Type Round | ||
Cable Length 30m | ||
Standards/Approvals UL, FT1, (UL) CL2, AWM Style 20267, National Electrical Code Article 725 | ||
Hi-Flex No | ||
Jacket Colour Black | ||
Number of Strands 7 | ||
Fire Behaviour VW-1 | ||
Minimum Operating Temperature -20°C | ||
Core Strands 7 x 36AWG | ||
Conductor Material Tin Plated Copper | ||
Maximum Operating Temperature 80°C | ||
Size of Strands 36AWG | ||
- COO (Country of Origin):
- US
3M 3659 Series Flat Cable, 30m Cable Length, 16 Conductors - 3659/16SF
This flat cable provides a screened multiconductor connection for internal wiring in control and electronic systems. It is designed for moderate-voltage signal and power distribution within assemblies, offering a Compact pitch suitable for high-density interconnects and a flexible PVC jacket for routed installations.
Features and Benefits:
• 16 conductors enable Compact multi-signal routing • 1.27mm pitch supports high-density connector compatibility • 28AWG round conductors reduce bulk while maintaining conductivity • Tin-plated copper with 7 strands improves solderability and flexibility • Screened construction minimises electromagnetic interference in harnesses • PVC jacket rated for -20°C to 80°C provides Durable environmental tolerance
Applications
• Suitable for internal wiring of automation control panels • Ideal for ribbon-to-board connections in electronic assemblies • Used with high-density 16-pin connector modules • Can be used for signalling runs in electrical distribution cabinets • Used for wiring harnesses in mechanical equipment enclosures
What voltage levels can this cable handle safely?
The cable is rated for use up to 300V, appropriate for low-voltage control and signal circuits.
How does the screening affect installation in confined spaces?
The screened wrap adds electromagnetic protection without significantly increasing overall cable diameter, aiding routing through tight conduits.
What fire behaviour classification applies to this cable?
It meets VW-1 flame test criteria and carries FT1 recognition for limited combustibility in installations.
Which standards and approvals does it comply with for installation use?
It conforms to UL classifications including CL2 and AWM Style 20267 and aligns with National Electrical Code Article 725 requirements.
How is the cable supplied for long runs?
It is available on a 30m length for continuous installations and easy reel handling.
Approvals
UL Listed
Warning
These cables are not to be regarded as power cables or cables for the direct connection of equipment to mains power supplies.
