Arcolectric (Bulgin) Ltd Illuminated Push Button Switch, Latching, Panel Mount, 16.2mm Cutout, DPDT, Blue LED, 250V ac,

RS Stock No.:: 187-3306
Mfr. Part No.:: MP0045/1E1BL012S
Manufacturer:: Arcolectric (Bulgin) Ltd

Arcolectric (Bulgin) Ltd Illuminated Push Button Switch, Latching, Panel Mount, 16.2mm Cutout, DPDT, Blue LED, 250V ac,

Bulk discount available

Subtotal (1 tray of 40 units)**

SGD1,851.84

(exc. GST)

SGD2,018.52

(inc. GST)

80 In stock for delivery within 4 working days*

* Delivery dates may change based on your chosen quantity and delivery address.

FREE delivery for orders over SGD150.00 (ex GST)

Real time qty checker

Units	Per unit	Per Tray**
40 - 40	SGD46.296	SGD1,851.84
80 - 120	SGD45.583	SGD1,823.32
160 +	SGD44.597	SGD1,783.88

**price indicative

RS Stock No.:: 187-3306
Mfr. Part No.:: MP0045/1E1BL012S
Manufacturer:: Arcolectric (Bulgin) Ltd

Datasheet MP0045/1E1BL012S

Bulgin MP0045/1E1 Series Push Button Switch, 16.2mm Panel Cut Out Diameter, 250V AC Voltage Rating - MP0045/1E1BL012S

This push button switch is designed for seamless integration in various applications. It features a round chrome push button and is illuminated with a blue LED, enhancing visibility in low-light conditions. With a panel cut-out diameter of 16.2mm, it is crafted for easy panel mounting. This switch is rated IP67, ensuring protection against dust and moisture, making it suitable for demanding environments.

Features & Benefits

• Latching mechanism provides reliable and secure operation
• Illuminated blue LED enhances visibility and user experience
• IP67 rating offers protection against dust and water
• DPDT configuration allows versatile circuit control
• Chrome push button adds a modern aesthetic to installations
• Operating temperature range from -20 to +55°C for wide usability

Applications

• Utilised in automation systems requiring secure switching
• Employed in electronics for circuit control and signalling
• Used in mechanical setups where robust components are required
• Suitable for outdoor due to its IP67 rating

What type of connection does this switch use?

It utilises solder tag terminals, providing a reliable connection for various wiring configurations.

How does the latching function enhance usability in industrial applications?

The latching feature ensures that the switch remains in its chosen position until manually reset, helping to prevent accidental shutdowns or changes during operation.

Can this switch handle both AC and DC voltage?

Yes, it has a contact AC voltage rating of 250 V and a contact DC voltage rating of 12V, making it versatile for different electrical systems.

What is the minimum temperature at which this switch can operate effectively?

The switch can function reliably at temperatures as low as -20°C, ensuring performance in cold environments.

Attribute	Value
Switch Operation	Latching
Illuminated	Yes
Panel Cut Out Diameter	16.2mm
Mounting Type	Panel Mount
Push Button Colour	Chrome
Contact Configuration	DPDT
Voltage Rating	250V ac
Push Button Style	Round
LED Colour	Blue
IP Rating	IP67
Contact Current Rating	3 A
Contact Material	Brass
Contact DC Voltage Rating	12V
Contact AC Voltage Rating	250V
Manufacturer Part No.	MP0045/1E1BL012S
Terminal Type	Solder Tag
