RS PRO Illuminated Push Button Switch, Latching, Panel, 19.2 mm Cutout, DPDT, Red LED, IP67 250 V ac
- RS Stock No.:
- 111-5793
- Manufacturer:
- RS PRO
Bulk discount available
Subtotal (1 unit)*
SGD19.86
(exc. GST)
SGD21.65
(inc. GST)
FREE delivery for orders over $150, or create a business account to enjoy free delivery from just $28
In Stock
- 354 unit(s) ready to ship from another location
- Plus 120 unit(s) shipping from 24 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | SGD19.86 |
| 10 - 24 | SGD19.44 |
| 25 - 49 | SGD18.85 |
| 50 - 99 | SGD18.40 |
| 100 + | SGD15.14 |
*price indicative
- RS Stock No.:
- 111-5793
- Manufacturer:
- RS PRO
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Switch Operation | Latching | |
| Product Type | Push Button Switch | |
| Actuator Colour | Silver | |
| Illuminated | Yes | |
| Panel Cutout Size | 19.2 mm | |
| Mount Type | Panel | |
| Contact Configuration | DPDT | |
| Terminal Type | Solder Pin | |
| LED Colour | Red | |
| IP Rating | IP67 | |
| Contact AC Voltage | 250V ac | |
| Actuator Style | Round | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | 55°C | |
| Switch Configuration | 2 NO/2 NC | |
| Standards/Approvals | UL 94-V0, UL 94-V2 | |
| Switch Contact Current | 5 A | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Switch Operation Latching | ||
Product Type Push Button Switch | ||
Actuator Colour Silver | ||
Illuminated Yes | ||
Panel Cutout Size 19.2 mm | ||
Mount Type Panel | ||
Contact Configuration DPDT | ||
Terminal Type Solder Pin | ||
LED Colour Red | ||
IP Rating IP67 | ||
Contact AC Voltage 250V ac | ||
Actuator Style Round | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature 55°C | ||
Switch Configuration 2 NO/2 NC | ||
Standards/Approvals UL 94-V0, UL 94-V2 | ||
Switch Contact Current 5 A | ||
- COO (Country of Origin):
- CN
RS PRO Double Pole Double Throw (DPDT) Latching Red LED Push Button Switch, IP67, 19.2 mm, Panel Mount, 250 V AC
This DPDT (Double Pole Double Throw) RS PRO push button switch can handle four independent output terminals while managing two different circuits at the same time. The latching push button holds the switch in the desired state until the button is pressed again, making the switch simple to use.
The red LED ring makes it simple to tell if the switch is on or off at a glance. Thanks to its compact size and panel-mounting design, it can be used in small areas where traditional switches would be inconvenient.
For a secure connection, the switch includes silver-plated copper contacts. It's frequently found in medical and communications equipment, as well as industrial control systems.
Features and Benefits
