Phoenix Contact SMKDSP 1.5/12-5.08 Series 55° Through Hole PCB Terminal Block, 12-Contact, 1 Row, 5.08 mm Pitch Screw
- RS Stock No.:
- 881-8812
- Mfr. Part No.:
- 1733677
- Manufacturer:
- Phoenix Contact
Bulk discount available
Subtotal (1 box of 50 units)*
SGD401.45
(exc. GST)
SGD437.60
(inc. GST)
FREE delivery for orders over $150, or create a business account to enjoy free delivery from just $28
Stocked by manufacturer
- Ready to ship from 11 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
|---|---|---|
| 50 - 200 | SGD8.029 | SGD401.45 |
| 250 - 450 | SGD7.761 | SGD388.05 |
| 500 + | SGD7.244 | SGD362.20 |
*price indicative
- RS Stock No.:
- 881-8812
- Mfr. Part No.:
- 1733677
- Manufacturer:
- Phoenix Contact
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | PCB Terminal Block | |
| Number of Contacts | 12 | |
| Sub Type | PCB Terminal Block | |
| Number of Rows | 1 | |
| Current | 17.5A | |
| Pitch | 5.08mm | |
| Housing Material | Polyamide | |
| Termination Type | Screw | |
| Mount Type | Through Hole | |
| Orientation | 55° | |
| Connector System | Wire-to-Board | |
| Series | SMKDSP 1.5/12-5.08 | |
| Minimum Operating Temperature | -40°C | |
| Contact Material | Copper Alloy | |
| Maximum Operating Temperature | 100°C | |
| Contact Plating | Tin | |
| Standards/Approvals | RoHS | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type PCB Terminal Block | ||
Number of Contacts 12 | ||
Sub Type PCB Terminal Block | ||
Number of Rows 1 | ||
Current 17.5A | ||
Pitch 5.08mm | ||
Housing Material Polyamide | ||
Termination Type Screw | ||
Mount Type Through Hole | ||
Orientation 55° | ||
Connector System Wire-to-Board | ||
Series SMKDSP 1.5/12-5.08 | ||
Minimum Operating Temperature -40°C | ||
Contact Material Copper Alloy | ||
Maximum Operating Temperature 100°C | ||
Contact Plating Tin | ||
Standards/Approvals RoHS | ||
- COO (Country of Origin):
- DE
PCB terminal block, nominal current: 17.5 A, rated voltage (III/2): 400 V, nominal cross section: 1.5 mm², Number of potentials: 12, Number of rows: 1, Number of positions per row: 12, product range: SMKDSP 1,5, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, mounting: Wave soldering, conductor/PCB connection direction: 55 °, color: green, Pin layout: Linear pinning, Solder pin [P]: 3.5 mm, type of packaging: packed in cardboard. The article can be aligned to create different nos. of positions!
