Samtec TSW Series Right Angle Through Hole Pin Header, 100 Contact(s), 2.54mm Pitch, 2 Row(s), Unshrouded

RS Stock No.:: 180-3483
Mfr. Part No.:: TSW-150-08-T-D-RA
Manufacturer:: Samtec

Samtec TSW Series Right Angle Through Hole Pin Header, 100 Contact(s), 2.54mm Pitch, 2 Row(s), Unshrouded

Bulk discount available

Subtotal (1 unit)**

SGD5.09

(exc. GST)

SGD5.55

(inc. GST)

Temporarily out of stock - back order for despatch 16/04/2025, delivery within 4 working days from despatch date*

* Delivery dates may change based on your chosen quantity and delivery address.

FREE delivery for orders over SGD150.00 (ex GST)

Units	Per unit
1 - 24	SGD5.09
25 - 99	SGD4.79
100 - 249	SGD4.42
250 - 499	SGD4.09
500 +	SGD3.79

**price indicative

RS Stock No.:: 180-3483
Mfr. Part No.:: TSW-150-08-T-D-RA
Manufacturer:: Samtec

Datasheet

Attribute	Value
Series	TSW
Pitch	2.54mm
Number of Contacts	100
Number of Rows	2
Body Orientation	Right Angle
Shrouded/Unshrouded	Unshrouded
Mounting Type	Through Hole
Connector System	Board to Board
Termination Method	Solder
Contact Plating	Tin
Contact Material	Phosphor Bronze
Current Rating	4.3A
Tail Pin Length	1.52mm
Mating Pin Length	5.84mm
Voltage Rating	400.0 V , 450.0 V ac, 500.0 V ac, 550.0 V ac

Samtec TSW Series Right Angle Through Hole Pin Header, 100 Contact(s), 2.54mm Pitch, 2 Row(s), Unshrouded

FREE delivery for orders over SGD150.00 (ex GST)

For these non-cancellable (NC), and non-returnable (NR) products, Terms and Conditions apply.
