Samtec HTSW Series Straight Through Hole Pin Header, 2 Contact(s), 2.54mm Pitch, 1 Row(s), Unshrouded
- RS Stock No.:
- 180-1939
- Mfr. Part No.:
- HTSW-102-08-G-S
- Manufacturer:
- Samtec
300 In stock for delivery within 4 working days
Added
Price Each (In a Pack of 10)
SGD0.314
(exc. GST)
SGD0.342
(inc. GST)
Units | Per unit | Per Pack* |
10 - 40 | SGD0.314 | SGD3.14 |
50 - 90 | SGD0.307 | SGD3.07 |
100 - 190 | SGD0.30 | SGD3.00 |
200 - 490 | SGD0.293 | SGD2.93 |
500 + | SGD0.286 | SGD2.86 |
*price indicative |
- RS Stock No.:
- 180-1939
- Mfr. Part No.:
- HTSW-102-08-G-S
- Manufacturer:
- Samtec
Technical data sheets
Legislation and Compliance
Product Details
Application: Large variety of standard pin counts, terminal lengths and options
Contact System: .025" (0.635 mm) square post
Orientation: Vertical, right-angle
Pitch: .100" (2.54 mm)
Special Features: Suitable for most high-temperature board processing
Termination: Through-hole
Contact System: .025" (0.635 mm) square post
Orientation: Vertical, right-angle
Pitch: .100" (2.54 mm)
Special Features: Suitable for most high-temperature board processing
Termination: Through-hole
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Specifications
Attribute | Value |
---|---|
Series | HTSW |
Pitch | 2.54mm |
Number of Contacts | 2 |
Number of Rows | 1 |
Body Orientation | Straight |
Shrouded/Unshrouded | Unshrouded |
Mounting Type | Through Hole |
Connector System | Board to Board |
Termination Method | Solder |
Contact Plating | Gold |
Contact Material | Phosphor Bronze |
Current Rating | 4.3A |
Tail Pin Length | 5.08mm |
Mating Pin Length | 5.84mm |
Voltage Rating | 400.0 V , 500.0 V ac, 550.0 V ac |
