Samtec TSW Series Right Angle Through Hole Pin Header, 3 Contact(s), 2.54mm Pitch, 1 Row(s), Unshrouded

RS Stock No.:: 180-0489
Mfr. Part No.:: TSW-103-08-F-S-RA
Manufacturer:: Samtec

Samtec TSW Series Right Angle Through Hole Pin Header, 3 Contact(s), 2.54mm Pitch, 1 Row(s), Unshrouded

Bulk discount available

Price Each (In a Pack of 10)

SGD0.505

(exc. GST)

SGD0.55

(inc. GST)

32 In stock for delivery within 4 working days*

* Delivery dates may change based on your chosen quantity and delivery address.

Units	Per unit	Per Pack**
10 - 40	SGD0.505	SGD5.05
50 - 90	SGD0.464	SGD4.64
100 - 190	SGD0.411	SGD4.11
200 - 490	SGD0.371	SGD3.71
500 +	SGD0.337	SGD3.37

**price indicative

RS Stock No.:: 180-0489
Mfr. Part No.:: TSW-103-08-F-S-RA
Manufacturer:: Samtec

Datasheet

Attribute	Value
Series	TSW
Pitch	2.54mm
Number of Contacts	3
Number of Rows	1
Body Orientation	Right Angle
Shrouded/Unshrouded	Unshrouded
Connector System	Board to Board
Mounting Type	Through Hole
Termination Method	Solder
Contact Material	Phosphor Bronze
Contact Plating	Gold
Current Rating	4.3A
Tail Pin Length	1.52mm
Mating Pin Length	5.84mm
Voltage Rating	400.0 V , 450.0 V ac, 500.0 V ac, 550.0 V ac

Samtec TSW Series Right Angle Through Hole Pin Header, 3 Contact(s), 2.54mm Pitch, 1 Row(s), Unshrouded
