Schneider Electric Phase, Voltage Monitoring Relay, 3 Phase, SPDT, 183 → 528V ac, DIN Rail

RS Stock No.:: 146-597
Mfr. Part No.:: RM17TU00
Manufacturer:: Schneider Electric

Schneider Electric Phase, Voltage Monitoring Relay, 3 Phase, SPDT, 183 → 528V ac, DIN Rail

Bulk discount available

Subtotal (1 unit)**

SGD210.06

(exc. GST)

SGD228.97

(inc. GST)

4 In Global stock for delivery within 5 working day(s)*

6 In Global stock for delivery within 4 working day(s)

* Delivery dates may change based on your chosen quantity and delivery address.

FREE delivery for orders over SGD250.00 (ex GST)

Units	Per unit
1 - 4	SGD210.06
5 - 9	SGD205.64
10 +	SGD199.47

**price indicative

Better World

Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.

RS Stock No.:: 146-597
Mfr. Part No.:: RM17TU00
Manufacturer:: Schneider Electric

RM17 Tx00 Series Three-Phase Network Control Relay

Schneider Electric RM17Tx00 Series multi-function 3 phase supply control relays. Monitoring the correct sequencing of phases L1, L2, and L3 and the total loss of one or more of each phase. In the event of a phase sequence or missing phase fault, the relay opens instantly. In the event of voltage fault, the relay opens at the end of the time delay set.

Clear hinged front cover
Front face potentiometer
LED output status
DIN rail

Phase, Asymmetry and Under-Voltage / Over-Voltage Controller: RM17 TE00

The relay monitors its own Un supply voltage:
The relay controls: the direct sequence of the three phases, the loss of at least one of the three phases (U measured < 0.7 x Un), asymmetry adjustable from 5 → 15 % of Un, over- and under-voltage drift in window mode adjustable from 2 → 20 % of Un.

Standards

NF EN 60255-6 and IEC 60255-6

Approvals

UL, CSA, GL, C-Tick, GOST

Schneider Electric Harmony Control Series Monitoring Relay, SPDT Contact Configuration, Phase/Voltage Monitoring Application - RM17TU00

This monitoring relay is tailored for effective phase voltage supervision and electrical phase management across diverse applications. It delivers essential undervoltage protection, ensuring that systems function within specified voltage parameters. Its robust design contributes to enhanced operational efficiency and safety in electrical systems.

Features & Benefits

• Monitors voltage levels from 183 to 528VAC for broad compatibility
• Adjustable time delay from 0.1 to 10s for customised responses
• SPDT configuration provides versatility in signal management
• Compact DIN rail relay optimises installation space
• Incorporates phase failure and sequence detection for improved system reliability
• Self-extinguishing housing enhances durability in demanding environments

Applications

• Utilised for phase voltage monitoring in industrial machinery
• Employed in automation systems requiring voltage sensing
• Provides undervoltage protection in electrical cabinets
• Suitable for electrical phase monitoring in power distribution networks

What is the installation process for this relay?

The relay can be mounted on a standard DIN rail, requiring only screw terminal connections for quick setup.

How does the time delay function enhance operation?

The time delay feature allows for adjustable settings, preventing unnecessary tripping during transient voltage drops.

Is it suitable for varying electrical environments?

Yes, it operates effectively within a wide temperature range and is designed for both industrial and commercial applications.

Can it be integrated into existing electrical systems?

The relay is compatible with common electrical setups and can be incorporated without extensive modifications.

What maintenance is required for optimal performance?

Regular inspections are advised to ensure terminals are secure and clean, although the device is designed for minimal upkeep.

Schneider Electric Voltage, Current, Phase & Motor Protection

Attribute	Value
Monitoring Application	Phase, Voltage
Electrical Phase	3
Contact Configuration	SPDT
Voltage Sensing Range	183 → 528V ac
Voltage Sensitivity	Undervoltage
Mounting Type	DIN Rail
Phase Sensitivity	Phase Failure, Phase Sequence
Time Delay	0.1 → 10s
Series	Harmony Control
Better World Product	Yes
Better World Verification	Green Premium
Length	72mm
Maximum Voltage Sensed	528V ac
Operating Temperature Range	-20 → +50°C
Terminal Type	Screw
Width	17.5mm
Maximum Operating Temperature	+50°C
Minimum Voltage Sensed	183V ac
Height	90mm
Standards Met	CE, CSA, UL
Special Features	IP20 Terminals
Minimum Operating Temperature	-20°C
Dimensions	72 x 17.5 x 90mm
