MEAN WELL LED Driver, 2/100 V Output, 42 W Output, 700 mA PWM, 1/10 V
- RS Stock No.:
- 771-7720
- Distrelec Article No.:
- 110-38-943
- Mfr. Part No.:
- LCM-40
- Manufacturer:
- MEAN WELL
Bulk discount available
Subtotal (1 unit)*
SGD45.06
(exc. GST)
SGD49.12
(inc. GST)
FREE delivery for orders over $150, or create a business account to enjoy free delivery from just $28
In Stock
- Plus 170 unit(s) shipping from 02 February 2026
- Plus 162 unit(s) shipping from 30 March 2026
- Plus 54 unit(s) shipping from 20 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | SGD45.06 |
| 5 - 9 | SGD43.71 |
| 10 - 24 | SGD42.40 |
| 25 - 124 | SGD41.13 |
| 125 + | SGD39.90 |
*price indicative
- RS Stock No.:
- 771-7720
- Distrelec Article No.:
- 110-38-943
- Mfr. Part No.:
- LCM-40
- Manufacturer:
- MEAN WELL
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | MEAN WELL | |
| Output Voltage | 2/100 V | |
| Product Type | LED Driver | |
| Maximum Output Power | 42W | |
| Input Voltage | 180 → 295 V ac, 254 → 417 V dc | |
| Mount Type | Screw | |
| Sub Type | LED Driver | |
| Dimming Operation | PWM, 1/10 V | |
| Input Voltage Type | AC/DC | |
| Terminal Type | Quick Connect | |
| IP Rating | IP20 | |
| Driver Current | 700 mA | |
| Operating Modes | Constant Current | |
| Number of Outputs | 5 | |
| Standards/Approvals | CE, UL, CB, SELV, ENEC | |
| Series | LCM-40 | |
| Configuration | Enclosed | |
| Primary Type | AC-DC | |
| Power Dissipation | 42W | |
| Select all | ||
|---|---|---|
Brand MEAN WELL | ||
Output Voltage 2/100 V | ||
Product Type LED Driver | ||
Maximum Output Power 42W | ||
Input Voltage 180 → 295 V ac, 254 → 417 V dc | ||
Mount Type Screw | ||
Sub Type LED Driver | ||
Dimming Operation PWM, 1/10 V | ||
Input Voltage Type AC/DC | ||
Terminal Type Quick Connect | ||
IP Rating IP20 | ||
Driver Current 700 mA | ||
Operating Modes Constant Current | ||
Number of Outputs 5 | ||
Standards/Approvals CE, UL, CB, SELV, ENEC | ||
Series LCM-40 | ||
Configuration Enclosed | ||
Primary Type AC-DC | ||
Power Dissipation 42W | ||
40W Multiple-Stage Output Current LED Power Supply LCM-40 Series
The LCM-40 series LED driver is a 40W multiple-stage output current LED power supply with built-in push dimming function. The series have built-in active PFC function, protections including short circuit, over voltage and over temperature. Fully isolated in a plastic case with strain relief design the unit is IP20 rated and is suitable for LED lighting applications.
Output current level selectable by DIP Switch
180∼295V ac input only
Built in active PFC function
Protection for short circuit, over voltage and over temperature
Cooling by free air convection
Fully isolated plastic case
Class II Power unit, no FG
Built in 0∼10Vdc and PWM signal dimming function
Built in 12V/50mA auxiliary output
IP20 design
Temperature compensation function by external NTC
No load power consumption <1W
Power supplies synchronization function up to 10 units
Suitable for LED lighting applications
3 years warranty
