    i-Autoc KSV Series Solid State Relay, DIN Rail or Panel Mount, 24V dc Coil

    i-Autoc
    RS Stock No.:
    135-3329
    Mfr. Part No.:
    KSV240D10-LM
    Manufacturer:
    i-Autoc
    View this category
    Temporarily out of stock - back order for despatch 06/03/2024, delivery within 4 working days from despatch date
    Add to Basket
    units

    Added

    Price Each

    SGD73.85

    (exc. GST)

    SGD79.76

    (inc. GST)

    unitsPer unit
    1 +SGD73.85
    RS Stock No.:
    135-3329
    Mfr. Part No.:
    KSV240D10-LM
    Manufacturer:
    i-Autoc

    Technical data sheets


    Legislation and Compliance

    COO (Country of Origin):
    CN

    Product Details

    I-Autoc KSV Series Single Phase SSR


    I-Autoc KSV Series industrial solid state relays with an integrated heatsink, designed for mounting on 35 mm DIN Rail or screwed onto a panel. The KSV SSR's offer four control voltage variations, in both AC or DC.

    Features and Benefits


    Zero crossing switching

    Ratings from 10A to 40A

    SCR Output

    DC or AC Input

    Integrated Heatsink

    Width 30 mm (10A to 30A) or 50 mm (40A)

    Dielectric Strength 4000 V ac RMS

    LED Indication

    Built-in RC Snubber Circuit

    Panel mount or 35mm Rail (DIN EN50022)


    Zero Voltage Relays

    Note

    Temperature can affect current rating; please consult the data sheet for potential derating.

    Specifications

    Attribute
    Value
    Coil Voltage24V dc
    Mounting TypeDIN Rail or Panel
    Terminal TypePCB Pin
    Depth30.5mm
    Height112.5mm
    Length100mm
    SeriesKSV
    Input Current15 (dc) mA, 25 (ac) mA
    Maximum Operating Temperature+80°C
    Operating Temperature Range-30 → +80°C
    Dimensions100 x 30.5 x 112.5mm
    Standards MetCE
    Minimum Operating Temperature-30°C
    Turn Off Time10 (DC) ms, 40 (AC) ms
    Special FeaturesBuilt-In RC Snubber Circuit, Dielectric Strength 4000 VACrmsLED Indication, Integerated Heatsink, SCR Output, Zero Crossing or Random-On Switching
    Turn On Time10 (DC), 40 (AC)
    Relay TypeSingle Phase
