RS PRO Stainless Steel Threaded Threaded BSP Single Check Valve 3/4 in, 14 bar
- RS Stock No.:
- 499-2650
- Manufacturer:
- RS PRO
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
SGD97.28
(exc. GST)
SGD106.04
(inc. GST)
FREE delivery for orders over $150, or create a business account to enjoy free delivery from just $28
In Stock
- 134 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 5 | SGD97.28 |
| 6 + | SGD94.37 |
*price indicative
- RS Stock No.:
- 499-2650
- Manufacturer:
- RS PRO
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Inlet Connection Type | Threaded | |
| Sub Type | Single | |
| Product Type | Check Valve | |
| Outlet Connection Type | Threaded | |
| Body Material | Stainless Steel | |
| Inlet Port Size | 3/4 in | |
| Maximum Operating Pressure | 14 bar | |
| Outlet Port Size | 3/4 in | |
| Inlet Thread Standard | BSP | |
| Inlet Port Gender | Female | |
| Outlet Port Gender | Female | |
| Minimum Operating Temperature | -20°C | |
| Outlet Thread Standard | BSP | |
| Maximum Operating Temperature | 180°C | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Inlet Connection Type Threaded | ||
Sub Type Single | ||
Product Type Check Valve | ||
Outlet Connection Type Threaded | ||
Body Material Stainless Steel | ||
Inlet Port Size 3/4 in | ||
Maximum Operating Pressure 14 bar | ||
Outlet Port Size 3/4 in | ||
Inlet Thread Standard BSP | ||
Inlet Port Gender Female | ||
Outlet Port Gender Female | ||
Minimum Operating Temperature -20°C | ||
Outlet Thread Standard BSP | ||
Maximum Operating Temperature 180°C | ||
Standards/Approvals No | ||
RoHS Status: Exempt
- COO (Country of Origin):
- CN
RS PRO Stainless Steel Single Non Return Valve 1 in BSP
This RS PRO non-return valve keeps liquids flowing only in a predetermined direction within your system. The valve is sealed by an interior plate that's free to swing but pushes against a seal when the liquid isn't flowing in the right direction.
The flow direction is clearly labelled on the side of the valve. It has 1-inch threaded end connectors for simple fitting on the majority of fluid systems of a compatible size.
The valve has a durable stainless steel body that can withstand harsh industrial conditions. Its design is suitable for hydraulic systems of up to 14 bar or for water flow control applications.
Features and Benefits
