MEAN WELL Switching Power Supply, HRPG-600-7.5 7.5V dc, 80A, 600 W, Input 85V ac to 370 V dc, 264V ac
- RS Stock No.:
- 705-9797
- Mfr. Part No.:
- HRPG-600-7.5
- Manufacturer:
- MEAN WELL
Subtotal (1 unit)*
SGD311.38
(exc. GST)
SGD339.40
(inc. GST)
FREE delivery for orders over $150, or create a business account to enjoy free delivery from just $28
Temporarily out of stock
- Shipping from 22 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | SGD311.38 |
*price indicative
- RS Stock No.:
- 705-9797
- Mfr. Part No.:
- HRPG-600-7.5
- Manufacturer:
- MEAN WELL
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | MEAN WELL | |
| Product Type | Switching Power Supply | |
| Maximum Output Voltage | 7.5V dc | |
| Number of Outputs | 1 | |
| Mount Type | Chassis | |
| Power | 600W | |
| Minimum Operating Temperature | -40°C | |
| SMPS Output Current | 80A | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | UL 6681, TUV BS ENEN 6681, EAC TP TC 004, ASNZS 668.1 | |
| Width | 105mm | |
| Weight | 1.6kg | |
| Length | 218mm | |
| Depth | 63.5mm | |
| Efficiency | 86% | |
| Series | HRPG-600 | |
| Maximum Input Voltage | 370, 264V dc | |
| Hazardous Area Certification | NO | |
| Output Current | 80A | |
| Minimum Input Voltage | 85V ac | |
| Select all | ||
|---|---|---|
Brand MEAN WELL | ||
Product Type Switching Power Supply | ||
Maximum Output Voltage 7.5V dc | ||
Number of Outputs 1 | ||
Mount Type Chassis | ||
Power 600W | ||
Minimum Operating Temperature -40°C | ||
SMPS Output Current 80A | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals UL 6681, TUV BS ENEN 6681, EAC TP TC 004, ASNZS 668.1 | ||
Width 105mm | ||
Weight 1.6kg | ||
Length 218mm | ||
Depth 63.5mm | ||
Efficiency 86% | ||
Series HRPG-600 | ||
Maximum Input Voltage 370, 264V dc | ||
Hazardous Area Certification NO | ||
Output Current 80A | ||
Minimum Input Voltage 85V ac | ||
- COO (Country of Origin):
- TW
HRPG-600 Series Single Output Power Supply with PFC Function
High efficiency, long life and high reliability
No load power consumption <0.75W
Built-in active PFC function
Built-in cooling fan ON-OFF control
Built-in DC OK signal
Built-in remote sense function
Built-in remote ON-OFF control
Short circuit, over load, over voltage and over temperature protection
Withstands 300Vac surge input for 5 seconds
Power factor correction to EN61000-3-2,-3
EMC compliance to EN55022 class B
Note
Power derates above 50°C.
MTBF to MIL-HDBK-217F.
MTBF to MIL-HDBK-217F.
Approvals
UL/cUL recognised, TUV, CB
Standards
UL60950-1, TUV EN60950-1
