KNITTER-SWITCH 8 Way Surface Mount DIP Switch 8PST, Flat Actuator
- RS Stock No.:
- 918-9941
- Mfr. Part No.:
- SBP 8108
- Manufacturer:
- KNITTER-SWITCH
40 In stock for delivery within 4 working days
Added
Price Each (In a Tube of 20)
SGD2.961
(exc. GST)
SGD3.227
(inc. GST)
| Units | Per unit | Per Tube* |
| 20 - 20 | SGD2.961 | SGD59.22 |
| 40 - 80 | SGD2.872 | SGD57.44 |
| 100 - 180 | SGD2.783 | SGD55.66 |
| 200 - 380 | SGD2.723 | SGD54.46 |
| 400 + | SGD2.664 | SGD53.28 |
| *price indicative | ||
- RS Stock No.:
- 918-9941
- Mfr. Part No.:
- SBP 8108
- Manufacturer:
- KNITTER-SWITCH
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
Knitter Switch SBP 8100 Series DIP Switches
The SBD 8100 series has been designed for surface mounting applications with various contact configurations available. The flat actuators are right angle mounted and operated by 20° vertical movement.
With a wide operating temperature range and a high mechanical life cycle they can be used in a variety of applications.
With a wide operating temperature range and a high mechanical life cycle they can be used in a variety of applications.
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Dual-In-Line Switches
Sub-miniature switches in a choice of configurations and actions. Note that these switches are not suitable for immersion cleaning unless stated otherwise.
Specifications
Attribute | Value |
|---|---|
| Number of Positions | 8 |
| Mounting Type | Surface Mount |
| Contact Material | Copper |
| Contact Configuration | 8PST |
| Package Style | DIP |
| Actuator Type | Flat |
| Contact Current Rating | 100 (Non-Switching) mA, 25 (Switching) mA |
| Mechanical Life | 2000Operations |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
| Operating Temperature Range | -40 → +85°C |
| Voltage Rating | 24 V dc, 50V dc |
| Dielectric Strength | 100V ac |
