KNITTER-SWITCH 4 Way PCB DIP Switch 4PST, Raised Actuator
- RS Stock No.:
- 918-9884
- Mfr. Part No.:
- DBS 61004
- Manufacturer:
- KNITTER-SWITCH
Temporarily out of stock - back order for despatch 23/09/2024, delivery within 4 working days from despatch date
Price Each (In a Tube of 51)
SGD1.467
(exc. GST)
SGD1.599
(inc. GST)
| Units | Per unit | Per Tube* |
| 51 - 51 | SGD1.467 | SGD74.817 |
| 102 - 204 | SGD1.423 | SGD72.573 |
| 255 - 459 | SGD1.379 | SGD70.329 |
| 510 - 969 | SGD1.35 | SGD68.85 |
| 1020 + | SGD1.32 | SGD67.32 |
| *price indicative | ||
- RS Stock No.:
- 918-9884
- Mfr. Part No.:
- DBS 61004
- Manufacturer:
- KNITTER-SWITCH
Technical data sheets
Legislation and Compliance
Product Details
Knitter Switch DBS 610xx Series DIP Switches
The DBS 610xx series has been designed for PCB through-hole mounting with various contact configurations available. The raised actuators are mounted on top of the body and operated with a horizontal sliding motion.
With a wide operating temperature range and a high mechanical life cycle they can be used in a variety of applications.
With a wide operating temperature range and a high mechanical life cycle they can be used in a variety of applications.
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Specifications
Attribute | Value |
|---|---|
| Number of Positions | 4 |
| Mounting Type | PCB |
| Contact Configuration | 4PST |
| Contact Material | Gold over Nickel Plated |
| Package Style | DIP |
| Actuator Type | Raised |
| Contact Current Rating | 100 (Non-Switching) mA, 25 (Switching) mA |
| Mechanical Life | 5000Operations |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
| Operating Temperature Range | -40 → +85°C |
| Voltage Rating | 24 V dc, 50V dc |
| Dielectric Strength | 500V dc |
