Arcolectric (Bulgin) Ltd Illuminated Push Button Switch, Momentary, Panel Mount, 16.2mm Cutout, DPDT, Green LED, 250V

RS Stock No.:: 187-3349
Mfr. Part No.:: MP0045/1D2GN220S
Manufacturer:: Arcolectric (Bulgin) Ltd

Arcolectric (Bulgin) Ltd Illuminated Push Button Switch, Momentary, Panel Mount, 16.2mm Cutout, DPDT, Green LED, 250V

Temporarily out of stock - back order for despatch 15/07/2024, delivery within 4 working days from despatch date

Added

Price Each

SGD44.05

(exc. GST)

SGD48.01

(inc. GST)

Units	Per unit
1 - 9	SGD44.05
10 - 19	SGD42.29
20 +	SGD40.53

RS Stock No.:: 187-3349
Mfr. Part No.:: MP0045/1D2GN220S
Manufacturer:: Arcolectric (Bulgin) Ltd

Technical data sheets

Datasheet MP0045/1D2GN220S

Legislation and Compliance

COO (Country of Origin):: CN

Product Details

Stainless Steel Double Pole Changeover Switches
16mm diameter
Choice of switch action depending on part code:
Part codes containing /1D1 or /1D2 - Momentary action
Part codes containing /1E1 or /1E2 - Latching action
Choice of Illumination style depending on part code:
Part codes containing /1D1 or /1E1 - Centre dot
Part codes containing /1D2 or /1E2 - Ring
Choice of LED colour, depending on part code: /RD - Red, /GN - Green, /AM - Amber, /BL - Blue
Choice of LED operating voltage depending on part code suffix: /012 - 12V DC, /220 - 220V DC
MP0045/1 Low Profile
MP0045/3 Prominent Button

For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.

Specifications

Attribute	Value
Switch Operation	Momentary
Illuminated	Yes
Panel Cut Out Diameter	16.2mm
Mounting Type	Panel Mount
Push Button Colour	Chrome
Contact Configuration	DPDT
Voltage Rating	250V ac
Push Button Style	Round
LED Colour	Green
IP Rating	IP67
Contact Current Rating	3 A
Contact Material	Brass
Contact AC Voltage Rating	250V
Manufacturer Part No.	MP0045/1D2GN220S
Contact DC Voltage Rating	220V
Terminal Type	Solder Tag
