Samtec HTSW, 3 Way, 1 Row, Straight PCB Header

  • RS Stock No. 180-2279
  • Mfr. Part No. HTSW-103-08-G-S
  • Manufacturer Samtec
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
Product Details

Application: Large variety of standard pin counts, terminal lengths and options
Contact System: .025" (0.635 mm) square post
Orientation: Vertical, right-angle
Pitch: .100" (2.54 mm)
Special Features: Suitable for most high-temperature board processing
Termination: Through-hole

Specifications
Attribute Value
Series HTSW
Pitch 2.54mm
Number of Contacts 3
Number of Rows 1
Body Orientation Straight
Shrouded/Unshrouded Unshrouded
Connector System Board to Board
Mounting Type Through Hole
Termination Method Solder
Contact Plating Gold
Contact Material Phosphor Bronze
Current Rating 4.3A
320 In stock for delivery within 3 working days
Price Each (In a Pack of 10)
SGD 0.75
(exc. GST)
SGD 0.80
(inc. GST)
units
Per unit
Per Pack*
10 - 40
SGD0.75
SGD7.50
50 - 90
SGD0.676
SGD6.76
100 - 190
SGD0.615
SGD6.15
200 - 490
SGD0.563
SGD5.63
500 +
SGD0.52
SGD5.20
*price indicative
