Molex Nano-Fit Series Right Angle Through Hole PCB Header, 4 Contact(s), 2.5mm Pitch, 2 Row(s), Shrouded
- RS Stock No.:
- 162-3690
- Mfr. Part No.:
- 105314-1104
- Manufacturer:
- Molex
3230 In stock for delivery within 4 working days
Added
Price Each (In a Bag of 10)
SGD1.333
(exc. GST)
SGD1.453
(inc. GST)
Units | Per unit | Per Bag* |
10 - 40 | SGD1.333 | SGD13.33 |
50 - 90 | SGD1.307 | SGD13.07 |
100 + | SGD1.281 | SGD12.81 |
*price indicative |
- RS Stock No.:
- 162-3690
- Mfr. Part No.:
- 105314-1104
- Manufacturer:
- Molex
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
Smallest fully isolated headers in the market
Ultra-low mate force terminal
Positive-lock housing with anti-snag design
Enables use of multi-layer boards by eliminating the need for through holes
Available in embossed tape for pick-and-place assembly
Multiple mechanical keying and color-coded options
Terminals available in gold and tin plating
Retention tang and contact rib
Terminal interface with 4 points of contact
Fully isolated terminals
Short electrical pat
Ultra-low mate force terminal
Positive-lock housing with anti-snag design
Enables use of multi-layer boards by eliminating the need for through holes
Available in embossed tape for pick-and-place assembly
Multiple mechanical keying and color-coded options
Terminals available in gold and tin plating
Retention tang and contact rib
Terminal interface with 4 points of contact
Fully isolated terminals
Short electrical pat
Nano-Fit Right Angle Header, Through Hole, 2.50mm Pitch, Dual Row, 4 Circuits, Tin (Sn) Plating, Black
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Specifications
Attribute | Value |
---|---|
Series | Nano-Fit |
Pitch | 2.5mm |
Number of Contacts | 4 |
Number of Rows | 2 |
Body Orientation | Right Angle |
Shrouded/Unshrouded | Shrouded |
Connector System | Wire to Board |
Mounting Type | Through Hole |
Termination Method | Solder |
Contact Plating | Tin |
Contact Material | Brass |
Current Rating | 6.5A |
Series Number | 105314 |
Voltage Rating | 250.0 V |
