Samtec TSW Series Straight Through Hole Pin Header, 2 Contact(s), 2.54mm Pitch, 1 Row(s), Unshrouded
- RS Stock No.:
- 155-7967
- Mfr. Part No.:
- TSW-102-07-F-S
- Manufacturer:
- Samtec
150 In stock for delivery within 4 working days
Added
Price Each (In a Pack of 50)
SGD0.149
(exc. GST)
SGD0.162
(inc. GST)
| Units | Per unit | Per Pack* |
| 50 - 200 | SGD0.149 | SGD7.45 |
| 250 - 450 | SGD0.146 | SGD7.30 |
| 500 - 2450 | SGD0.139 | SGD6.95 |
| 2500 - 4950 | SGD0.132 | SGD6.60 |
| 5000 + | SGD0.128 | SGD6.40 |
| *price indicative | ||
- RS Stock No.:
- 155-7967
- Mfr. Part No.:
- TSW-102-07-F-S
- Manufacturer:
- Samtec
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- US
Product Details
This through-hole .025” square post terminal strip features single, double and triple row options with straight or right-angle pins in a variety of post heights and body positions. This connector is an Extended Life Product™, passing 10 year Mixed Flowing Gas (MFG) and achieving high mating cycles (250 to 2,500).
Pitch: .100" (2.54 mm)
Contact System: .025" (0.635 mm) square post
Orientation: Vertical, right-angle
Termination: Through-hole
Application: Industry's largest variety of standard pin counts, terminal lengths and options
Special Features: Many options for optimizing cost and performance with platings and ruggedizing features
Contact System: .025" (0.635 mm) square post
Orientation: Vertical, right-angle
Termination: Through-hole
Application: Industry's largest variety of standard pin counts, terminal lengths and options
Special Features: Many options for optimizing cost and performance with platings and ruggedizing features
Specifications
Attribute | Value |
|---|---|
| Series | TSW |
| Pitch | 2.54mm |
| Number of Contacts | 2 |
| Number of Rows | 1 |
| Body Orientation | Straight |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board to Board, Wire to Board |
| Mounting Type | Through Hole |
| Termination Method | Solder |
| Contact Material | Phosphor Bronze |
| Contact Plating | Gold |
| Current Rating | 4.3A |
| Voltage Rating | 400.0 V , 450.0 V ac, 500.0 V ac, 550.0 V ac |
