General Industrial Foot Switch, Die Cast Aluminium Momentary SPDT 6 A @ 250 V ac 250V IPX2

  • RS Stock No. 321-060
  • Manufacturer RS PRO
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): GB
Product Details

RS PRO Medium Duty Industrial Foot Switch

RS PRO medium duty foot switches which are ideal for general industrial applications This foot switch is constructed from die-cast aluminium making it tough and durable for harsh environments and is black in colour.

Foot switches are commonly used on large machinery were hand operated switches are a safety concern. RS PRO offers a range of footswitches and accessories to meet your requirements. The range has been RS approved meaning great value for money and high-quality you can rely on.

Features and Benefits:

Momentary foot switch controller
Die-cast aluminium body for durability
Single pole momentary changeover contact rated at 240V, 3A.
9mm rubber gland cable entry
Suited for medium/heavy duty industrial applications
Designed to reduce operator fatigue
Operating Temperature: -5°C to +40°C

Typical Applications

Foot switches are commonly used in applications where hands-free control is more practical or safer. They can be found on:
Industrial machinery and smaller power tools
Hospital beds
Dentist Chairs
Lamps

FAQs

What are the different types of switching options?
Switches are components that switch a circuit on or off by making contact or breaking contact, the two most common are:

Non-latching (Momentary) – this type of foot switch makes contact when you push it but breaks contact when you release it.

Latching (Maintained) – this type of foot switch needs to be pressed once for ON and again for OFF

Why would you use a footswitch?
As these switches are operated by the person’s feet, this means that their hands are free so therefore allows the individual to multitask.

Approvals

EN 61058-2-1; EN 61058; EN 60601-1; EN 60950

Specifications
Attribute Value
Contact Configuration SPDT
Switch Operation Momentary
Case Material Die Cast Aluminium
Contact Voltage Rating AC 250V
Contact Voltage Rating DC 24V
Contact Current Rating 6 A @ 250 V ac
Switch Environment General Industrial
IP Rating IPX2
Contact Material Silver
Colour Black
Standards Met EN 60950, 2006/95/EC
Dimensions 152 x 94 x 46mm
Width 94mm
Height 46mm
Length 152mm
198 In stock for delivery within 3 working days
Price Each
SGD 98.16
(exc. GST)
SGD 105.03
(inc. GST)
units
Per unit
1 - 5
SGD98.16
6 - 11
SGD94.24
12 +
SGD93.36
