Seeit VERYPRO-390 VERYPRO-390, Universal Programmer for Logic Devices, Memory Devices, Microcontrollers, PLD

  • RS Stock No. 772-3090
  • Mfr. Part No. VERYPRO-390
  • Manufacturer Seeit
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): CN
Product Details

VERYPRO-390, Universal Programmer for 21000 devices, with ZIF48 Socket, USB 2.0

The VERYPRO-390 is a Universal Programmer with 48-pins Zero Insertion Force (ZIF) socket and USB 2.0 interface for EPROMs, EEPROMs, FLASH Memory, PLD (CPLD, EPLD, GAL, PEEL, PALCE and more), and Microcontrollers with TTL/CMOS ICs test software. The programmer is reliable, and fast. It is designed to connect/operate with a personal computer. The menu-driven software interface makes it easy to operate with pull-down menus, pop-up dialogue box and help. Supports all main operations, such as program, verify, blank check, read, secure, erase and so on.

Accepts standard file formats: JEDEC, INTEL (Extended) HEX, HOLTEK, EMC(.CDS), INTEL HEX16, Motorola S record,
BINARY, Tektronix (linear & segmented), and auto find format
Manages 16-bit and 32-bit word split (Set Programming)
Features Test Vector capability and multi-array fuse map editor
Test TTL/CMOS logic ICs and Dynamic/Static Random Access Memory devices
Optimum programming for each individual device
Automatically identifies the manufacturer and type of EPROM/EEPROM, auto identifies TTL/CMOS logic IC
Device insertion test and poor pin contact check
Modify algorithm parameters
Set addresses intelligently, such as device start address, device end address, from buffer address and so on
Support down to 1.5V low voltage supply devices
Not need of an exterior adapter for most devices
Support for universal DIP, PLCC, QFP, TSOP, PSOP, SOIC, SSOP, SDIP standard adapters (support from 6-pin to 300-pin device packages)
Auto-Run mode starts programming automatically upon detection of chip insertion
Auto system test. Mass production mode
Supports Windows XP / Vista / Windows 7 (32-bit and 64-bit) with 100MB of spare capacity
Power Supply: AC/DC Adapter with AC input 100V to 240V, 50Hz/60Hz, output 9Vdc/0.6A
Interface: connect to computer through the USB port (USB 2.0)
Dimensions: 168 x 98 x 23 mm
Weight: 265g

Kit Contents

Programmer with 48-pins Zero Insertion Force (ZIF) socket
Power Supply
USB cable
Software on CD-ROM

PC Based Programmers

Specifications
Attribute Value
Accessory Type Universal Programmer
For Use With Logic Devices, Memory Devices, Microcontrollers, PLD
Interface USB 2.0
Programmer Name VERYPRO-390
Memory Type Programmed EEPROM, EPROM, FLASH
1 In stock for delivery within 4 working days
Price Each
SGD 474.29
(exc. GST)
SGD 507.49
(inc. GST)
units
Per unit
1 +
SGD474.29
