ebm-papst Hot Gas Centrifugal Fan, 200m³/h, 230 V ac AC (R2K Series)

  • RS Stock No. 278-1565
  • Mfr. Part No. R2K150-AC01-15
  • Manufacturer ebm-papst
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): DE
Product Details

ebm-papst Hot Gas Blower

The ebm-papst 230VAC hot air blower is rugged and reliable, with a steel construction which ensures long fault-free life. This fan has a speed of 2000rpm and provides airflow of 200m3/h. This centrifugal impeller fan is designed for circulating hot air.

Features and Benefits

Stainless steel impeller
Ball bearing
Maximum impeller temperature is 300°C
Maximum motor temperature is 120°C

Applications

Cooking
Curing paint or hardening

Certifications

EN60335
VDE
approved

Approvals

VDE;

Specifications
Attribute Value
Supply Voltage 230 V ac
Blower Type Hot Gas
AC or DC Operation AC
Air Flow 200m³/h
Series R2K
Width 152mm
Depth 98.5mm
Fan Speed 2000rpm
Bearing Type Ball
Mounting Hole Diameter 4.3mm
